Option Explicit

Public Sub 차트생성()
    '// ---------------- 시트/마지막행 ----------------
    Dim ws As Worksheet: Set ws = ActiveSheet
    Dim eRow As Long: eRow = ws.Cells(ws.Rows.Count, "A").End(xlUp).Row
    If eRow < 2 Then MsgBox "데이터가 없습니다.", vbExclamation: Exit Sub

    '// ---------------- 기준 선택 ----------------
    Dim rngSel As Range, 기준 As String, useAmt As Boolean
    On Error Resume Next
    Set rngSel = Application.InputBox( _
        Prompt:="C1=판매량, D1=총판매금액 중 하나의 셀을 클릭하세요", _
        Title:="기준 선택", Type:=8)
    On Error GoTo 0
    If rngSel Is Nothing Then Exit Sub

    If Not Application.Intersect(rngSel, ws.Range("C1")) Is Nothing Then
        기준 = "판매량": useAmt = False
    ElseIf Not Application.Intersect(rngSel, ws.Range("D1")) Is Nothing Then
        기준 = "총판매금액": useAmt = True
    Else
        MsgBox "반드시 C1 또는 D1 셀을 선택해야 합니다.", vbExclamation
        Exit Sub
    End If

    '// 기준 선택에서 사용할 열 번호 결정
    Dim mCol As Long
    If useAmt Then
        mCol = 4   '// 총판매금액: D열
    Else
        mCol = 3   '// 판매량: C열
    End If

    '// ---------------- 지점 범위(비연속 허용) 선택 ----------------
    Dim rSel As Range
    On Error Resume Next
    Set rSel = Application.InputBox( _
        Prompt:="지점명이 들어있는 셀 범위를 선택하세요." & vbCrLf & _
                "Ctrl 키를 누른 채로 여러 범위를 클릭/드래그하면 다중 선택됩니다.", _
        Title:="지점 다중 선택(비연속 허용)", Type:=8)
    On Error GoTo 0
    If rSel Is Nothing Then Exit Sub

    '// ---------------- 선택범위 → 지점 고유목록 ----------------
    Dim dBr As Object: Set dBr = CreateObject("Scripting.Dictionary")
    Dim ar As Range, c As Range, br As String
    For Each ar In rSel.Areas
        For Each c In ar.Cells
            br = Trim$(CStr(c.Value))
            If Len(br) > 0 Then dBr(br) = 1
        Next c
    Next ar
    If dBr.Count = 0 Then MsgBox "선택 범위에 지점명이 없습니다.", vbExclamation: Exit Sub

    '// ---------------- 원본에 실제 존재하는 지점만 남기기 ----------------
    Dim dExist As Object: Set dExist = CreateObject("Scripting.Dictionary")
    Dim i As Long
    For i = 2 To eRow
        br = CStr(ws.Cells(i, 1).Value)
        If Len(br) > 0 Then dExist(br) = 1
    Next
    Dim brs() As String, nBr As Long, k As Variant
    ReDim brs(1 To dBr.Count)
    For Each k In dBr.Keys
        If dExist.Exists(k) Then
            nBr = nBr + 1
            brs(nBr) = CStr(k)
        End If
    Next
    If nBr = 0 Then MsgBox "선택한 지점이 원본 데이터에 없습니다.", vbExclamation: Exit Sub
    ReDim Preserve brs(1 To nBr)

    '// ---------------- 축 최소/최대 입력 ----------------
    Dim tMin As String, tMax As String, minAuto As Boolean, maxAuto As Boolean
    Dim vMin As Double, vMax As Double
    tMin = Application.InputBox("Y축 최소값 (빈칸 또는 'auto' = 자동)", "축 최소값", Type:=2)
    tMax = Application.InputBox("Y축 최대값 (빈칸 또는 'auto' = 자동)", "축 최대값", Type:=2)
    minAuto = (Len(Trim$(tMin)) = 0 Or LCase$(Trim$(tMin)) = "auto")
    maxAuto = (Len(Trim$(tMax)) = 0 Or LCase$(Trim$(tMax)) = "auto")
    If Not minAuto Then
        If Not IsNumeric(tMin) Then MsgBox "최소값이 숫자가 아닙니다.", vbExclamation: Exit Sub
        vMin = CDbl(tMin)
    End If
    If Not maxAuto Then
        If Not IsNumeric(tMax) Then MsgBox "최대값이 숫자가 아닙니다.", vbExclamation: Exit Sub
        vMax = CDbl(tMax)
    End If
    If (Not minAuto And Not maxAuto) Then
        If vMax <= vMin Then MsgBox "최대값은 최소값보다 커야 합니다.", vbExclamation: Exit Sub
    End If

    '// ---------------- 차트 모드 선택: 0=개별차트, 1=전체차트 ----------------
    Dim modeSel As Variant, isCombined As Boolean, modeVal As Long
    modeSel = Application.InputBox("차트 모드 선택: 0=개별차트, 1=전체차트", "차트 모드", 1, Type:=1)

    '// 취소 시 종료
    If VarType(modeSel) = vbBoolean Then Exit Sub

    '// 숫자 보장 및 검증
    modeVal = CLng(modeSel)
    If modeVal <> 0 And modeVal <> 1 Then
        MsgBox "0 또는 1만 입력하세요.", vbExclamation: Exit Sub
    End If
    isCombined = (modeVal = 1)


    '// ===== 성능옵션  =====
    Dim sc As Boolean, ev As Boolean, calc As XlCalculation
    sc = Application.ScreenUpdating
    ev = Application.EnableEvents
    calc = Application.Calculation
    Application.ScreenUpdating = False
    Application.EnableEvents = False
    Application.Calculation = xlCalculationManual
    On Error GoTo XIT

    '// ---------------- 카테고리(모델) 목록: 등장순 유지 ----------------
    Dim dItm As Object: Set dItm = CreateObject("Scripting.Dictionary")
    Dim itm As String
    For i = 2 To eRow
        If InArray(CStr(ws.Cells(i, 1).Value), brs) Then
            itm = CStr(ws.Cells(i, 2).Value)
            If Len(itm) > 0 Then
                If Not dItm.Exists(itm) Then dItm.Add itm, dItm.Count + 1
            End If
        End If
    Next
    If dItm.Count = 0 Then MsgBox "선택 지점에 해당하는 항목이 없습니다.", vbExclamation: GoTo XIT

    Dim cats() As String, nCat As Long: nCat = dItm.Count
    ReDim cats(1 To nCat)
    For Each k In dItm.Keys
        cats(dItm(k)) = CStr(k)
    Next

    '// ---------------- 값 배열 구성 (지점 r, 항목 j) ----------------
    Dim vals() As Variant, r As Long, j As Long, v As Variant
    ReDim vals(1 To nBr, 1 To nCat)
    For r = 1 To nBr
        For j = 1 To nCat: vals(r, j) = 0: Next j
    Next r

    For i = 2 To eRow
        br = CStr(ws.Cells(i, 1).Value)
        If InArray(br, brs) Then
            itm = CStr(ws.Cells(i, 2).Value)
            If dItm.Exists(itm) Then
                j = dItm(itm)
                r = FindIndex(brs, br)
                If r > 0 Then
                    v = ws.Cells(i, mCol).Value               '// 선택 열 원값 그대로
                    If IsNumeric(v) And Len(v) > 0 Then
                        vals(r, j) = CDbl(v)                  '// 덮어쓰기
                    Else
                        vals(r, j) = 0
                    End If
                End If
            End If
        End If
    Next i

    If isCombined Then
        '// ========== 전체차트(한 개) ==========
        Const CH_NAME As String = "매장차트"
        Dim co As ChartObject, ch As Chart
        On Error Resume Next
        Set co = ws.ChartObjects(CH_NAME)
        On Error GoTo XIT
        If co Is Nothing Then
            Set co = ws.ChartObjects.Add(Left:=400, Top:=60, Width:=820, Height:=380)
            co.Name = CH_NAME
        End If
        Set ch = co.Chart
        ch.ChartType = xlColumnClustered

        Do While ch.SeriesCollection.Count > 0
            ch.SeriesCollection(1).Delete
        Loop

        For r = 1 To nBr
            With ch.SeriesCollection.NewSeries
                .Name = brs(r)
                .XValues = cats
                .Values = Application.Index(vals, r, 0)
            End With
        Next r
        ch.HasTitle = True
        ch.ChartTitle.Text = "지점별 " & 기준 & " 비교"

        With ch.Axes(xlValue)
            If minAuto Then .MinimumScaleIsAuto = True Else .MinimumScaleIsAuto = False: .MinimumScale = vMin
            If maxAuto Then .MaximumScaleIsAuto = True Else .MaximumScaleIsAuto = False: .MaximumScale = vMax
            .MajorGridlines.Format.Line.Visible = msoTrue
            If useAmt Then .TickLabels.NumberFormat = "\#,##0" Else .TickLabels.NumberFormat = "#,##0"
        End With

    Else
        '// ========== 개별차트(지점마다 1개씩) ==========
        Dim perW As Double, perH As Double, padX As Double, padY As Double
        Dim colCnt As Long, rIdx As Long, cIdx As Long
        Dim nameOne As String, co1 As ChartObject, ch1 As Chart  '// 루프 밖으로 이동
        perW = 380: perH = 300  '// 차트 크기
        padX = 20: padY = 20    '// 간격
        colCnt = 2              '// 한 줄에 2개 배치 (원하면 3으로 변경)

        For r = 1 To nBr
            nameOne = "매장차트_" & brs(r)
            Set co1 = Nothing  '// 변수 초기화
            Set ch1 = Nothing  '// 변수 초기화

            On Error Resume Next
            Set co1 = ws.ChartObjects(nameOne)
            On Error GoTo 0

            If co1 Is Nothing Then
                Set co1 = ws.ChartObjects.Add(Left:=0, Top:=0, Width:=perW, Height:=perH)
                co1.Name = nameOne
            Else
                co1.Width = perW: co1.Height = perH
            End If

            Set ch1 = co1.Chart  '// Chart 객체를 설정

            '// 배치
            rIdx = (r - 1) \ colCnt
            cIdx = (r - 1) Mod colCnt
            co1.Left = 20 + cIdx * (perW + padX)   '// 시작 위치를 살짝 왼쪽으로 (겹침 방지)
            co1.Top = 60 + rIdx * (perH + padY)

            ws.Shapes(co1.Name).ZOrder 0

            '// 차트 타입 설정
            ch1.ChartType = xlColumnClustered

            '// 기존 시리즈 삭제
            Do While ch1.SeriesCollection.Count > 0
                ch1.SeriesCollection(1).Delete
            Loop

            With ch1.SeriesCollection.NewSeries
                .Name = brs(r)
                .XValues = cats
                .Values = Application.Index(vals, r, 0)
            End With
            ch1.HasTitle = True
            ch1.ChartTitle.Text = brs(r) & " - " & 기준

            With ch1.Axes(xlValue)
                If minAuto Then .MinimumScaleIsAuto = True Else .MinimumScaleIsAuto = False: .MinimumScale = vMin
                If maxAuto Then .MaximumScaleIsAuto = True Else .MaximumScaleIsAuto = False: .MaximumScale = vMax
                .MajorGridlines.Format.Line.Visible = msoTrue
                If useAmt Then .TickLabels.NumberFormat = "\#,##0" Else .TickLabels.NumberFormat = "#,##0"
            End With
        Next r
    End If

    MsgBox IIf(isCombined, "전체차트 1개 생성/갱신 완료.", "개별차트 " & nBr & "개 생성/갱신 완료.") & vbCrLf & _
           "기준: " & 기준 & vbCrLf & _
           "Y축 최소: " & IIf(minAuto, "자동", CStr(vMin)) & ", 최대: " & IIf(maxAuto, "자동", CStr(vMax)), vbInformation

XIT:
    On Error Resume Next
    Application.ScreenUpdating = sc
    Application.EnableEvents = ev
    Application.Calculation = calc
End Sub

'// --------- 유틸 ----------
Private Function InArray(ByVal s As String, a() As String) As Boolean
    Dim i As Long
    For i = LBound(a) To UBound(a)
        If s = a(i) Then InArray = True: Exit Function
    Next
End Function

Private Function FindIndex(a() As String, ByVal s As String) As Long
    Dim i As Long
    For i = LBound(a) To UBound(a)
        If a(i) = s Then FindIndex = i: Exit Function
    Next
End Function
